STRIAGHT SIDED BAKELITE PRESSES
S.B.K 200/45-1000
KN
2000Press Capacity
mm
750Stroke
mm 1000 × 1000
Area of Bed
mm 980 × 950
Area of Slide
mm Max. 850
Open Shut Height
mm/sec 170
Closing Speed
mm/sec 7
Pressing Speed
KN 450
Cushion Capacity
mm 500 × 500
Cushion Bed Area
mm 200
Cushion Stroke
H7 110 Ø
Bed Bore Holes
Kw 18.5
Power Consumption
P.L.C+H.M.I
Control System
kg 10000
Weight
lit 600
Oil Reservoir Tank Capacity
mm .2000W. × 1500D. × 4200H
Overall Dimensions
